Cast Steel Ductile Iron Rising Stem Gate Valve 明杆铸铁闸阀

applicable medium：water

适用介质：水

working temperature：ordinary temperature

工作温度：普通温度

construction：straight-through

类型：直通型

material：carbon steel，stainless steel

材料：碳钢，不锈钢

type of connection：flange

连接方式：法兰

Pressure environment：ordinary pressure

压力环境：普通压力

Sealing surface configuration：wedge gate valve

密封面配置：楔式闸阀

drive mode：manual

驱动方式：人工操作
Stem threaded position：outside gate valve

阀杆上螺纹位置：外螺纹阀杆闸阀阀

application： regulation

用途：调节

application：industrial usage

应用：工业

standard：ANSI

标准：ANSI

transport package：plywood case

运输包装：胶合板箱

specification：50/PC

规格：50/PC

brand：GUTE

商标：GUTE

1.Compact structure and reasonable design . The valve has fine stiffness , with small flow resistance
2.Adopt stainless steel and hard alloy for sealing surface, long service life
3.There is backseat structure in the valve , so the sealing is reliable
4.The materials of the spare parts and the flange dimensions can be selected according to the practical working conditions and customer's requirement , to meet the requirements of different projects

1.结构紧凑，设计合理。该阀刚性好，流动阻力小

2.密封面采用不锈钢及硬质合金，使用寿命长

3.阀内设有后座结构，密封可靠

4.零件的材料和法兰尺寸可根据实际工况和客户要求进行选择，以满足不同工程的要求
